@startuml skinparam style strictuml skinparam defaultFontName Helvetica,Arial,sans-serif skinparam backgroundcolor transparent scale 1 skinparam sequenceMessageAlign center skinparam participantPadding 10 skinparam sequenceBoxBorderColor transparent actor ":Joueur" as j box "Couche présentation" #ddffdd participant ":Button" as b << NavigateurWeb >> participant ":Routeur" as r << NodeExpress >> end box box "Couche domaine" #ddddff participant ":JeuRisk" as c << ContrôleurGRASP >> participant "..." as s end box j -> b : cliquer b ->> r : HTTP GET\n/api/v1/démarrerAttaque/... note over r : Router handler (Express) r ->> r : démarrerAttaque note over r, c: Opération système définie dans DSS r -> c : **<size:18>démarrerAttaque(...)** c -> s : ... note over c, s : selon la RDCU @enduml
