@startuml
skinparam backgroundColor #f5efe2
skinparam shadowing false
skinparam class {
  BackgroundColor #fdfaf0
  BorderColor #b8a982
  ArrowColor #6e5d3d
  FontName "Helvetica"
}
skinparam note {
  BackgroundColor #f0e3c4
  BorderColor #b8a982
}
hide empty members

class "Pet Translator" as pet_translator <<system>> #2c4a6b {
  inference_model_status : enum{idle,processing,ready}
  local_storage_capacity : number
}
class "Pet Owner" as pet_owner <<actor>> {
  pet_type : enum{dog,cat}
  experience_level : string
}
class "Audio Input" as audio_input <<block>> {
  vocalization_data : string
  recording_duration : number
}
class "Video Input" as video_input <<block>> {
  body_language_data : string
  frame_rate : number
}
class "Pet Behavior Data" as pet_behavior_data <<block>> {
  emotional_state : enum{playful,curious,aggressive,calm}
  interpreted_message : string
}

class "On-device inference for privacy" as on_device_inference <<constraint>> {
}
class "Honest about the difference between 'emotion classification' and 'translation'" as honest_disclosure <<constraint>> {
}

pet_owner --> pet_translator : uses
audio_input --> pet_translator : feeds_into
video_input --> pet_translator : feeds_into
pet_translator --> pet_behavior_data : generates
on_device_inference ..> pet_translator : applies_to
honest_disclosure ..> pet_translator : applies_to

legend right
  **Requirements**
  **REQ-001** — Provides a believable and useful interpretation of the pet's vocalization.
  **REQ-002** — Provides a believable and useful interpretation of the pet's body language.
endlegend
@enduml
